Sigma Controls 8-Channel Voice Output Autodialer, VM500
Images are representations only.

VM500 8-Channel Voice Output Autodialer

Brand: Sigma Controls, Inc.

Features:
  • 8 Dry contact or 24 Vac/dc inputs
  • Programmable open or closed inputs
  • Programmable time delay for each input
  • Optional 120 Vac inputs
  • Individual message for each channel in users voice
  • Fully programmable
  • Line 'Seizure' feature
  • Battery backup standard
  • Integral power fail alarm
  • Local alarm acknowledge
  • Telephone/Pager alerts
  • Integral remotely controlled relay

    • Specifications

    Brand

    Alarm

    • Alarm Buzzer: 85 dB

    Approvals & Certifications

    • Alarm Alert: FCC Approved & Registered
    • Power Supply: UL Listed

    Electrical Connectors

    • 3 Pluggable 8 Position Terminal Block

    Electrical Contacts

    • Input: Normally Closed (N/C), Programmable
    • Input: Normally Open (N/O), Programmable

    Enclosure, Body Material

    • Flame Retardant ABS Plastic, 94-5VA

    Input

    • VM500-6 & VM500-6-LV: Dry Contact, 12 Vdc at 10 mA Source
    • VM500-6-HV: 120 Vac
    • VM500-6-HV: Externally Powered, 90-130 Vac
    • VM500-6-LV: 24 Vac/dc
    • VM500-6-LV: Externally Powered, 17-48 Vac
    • VM500-6-LV: Externally Powered, 6-48 Vdc

    Input Signal

    • Dry Contact Input

    Operating Temperature

    • Ambient Operating: 0° to 52° C (32° to 125° F)

    Power Requirement

    • 120 Vac at 50/60 Hz with Wall Mount Transformer

    Relay Output

    • Alarm Relay: 125 Vac / 5 A Contacts

    Documentation

    Data Sheets
